Bonovo Equipment Sales |Durable skeleton screening bucket sieve bucket of all sizes
Excavator Range: 1-50T
Grid Size: Customizable
Bucket Type: with teeth/ bolt on
Recommended Applications: applied to excavation of relatively loose materials in governmental, agricutural, forestry, water conservancy projects.
In order to achieve a more perfect fit, Bonovo can customize the size according to the needs of customers.
Skeleton Bucket
The Primary Function of a Skeleton Bucket is the Removal of Rock and Debris without the Soil. Other Applications Include the Sorting Rocks of a Specific Size from Piles. Our Skeleton Buckets are Designed to Attack all Varieties of Applications from Demolition to Standard Stock Piles. The Skeletal Design is Set to Cater for Smaller as well as Larger Objects to Achieve Your Goals.
Bonovo Skeleton Screening Bucket is widely applied to loose materials in governmental, agricultural, forestry, water conservancy projects,screens size accept customization based on customers' working environment.
Commonly used tonnage parameters:
| Tonnes | Bucket Type | Width&Grills | G.E.T | Sidebar | Weight | |
| 3T | Skeleton Buket | 1100mm 75mm*75mm |
J200 Series 7PCS |
2713-6050/51 | 127KG | |
| 5T | Skeleton Buket | 1200mm 75mm*75mm |
J220 Series 7PCS |
PC60 | 218KG | |
| 8T | Skeleton Buket | 1500mm 75mm*75mm |
J220 series 7PCS |
PC60 | 350KG | |
| 13T | Skeleton Buket | 1800mm 100mm*100mm |
J250 series 8PCS |
7Y0203/04 | 795KG | |
| 20T | Skeleton Buket | 2000mm 125mm*125mm |
J350 series 8PCS |
296-4747/48 | 1226KG | |
| 30T | Skeleton Buket | 2200mm 125mm*125mm |
J450 series 8PCS |
7Y0357/58 | 2010KG | |
